A heavier pilot-control mini excavator designed for increased stability and digging force.
The GT950 Pilot Control combines a heavier counterweight, ergonomic pilot joysticks and a larger frame for gardens, farms, allotments and contractor work.
Why this model
Product highlights
| Operating weight | 950 kg |
|---|---|
| Engine | Briggs & Stratton 13.5 HP petrol |
| Boom | Swing boom as standard |
| Boom swing left / right | 45° / 45° |
| Auxiliary hydraulics | 3-way hydraulic valve as standard |
| Cylinder protection | Boom, arm and bucket |
| Hydraulic pump | Double |
| Hydraulic flow rate | 22–24 L/min |
| Hydraulic tank capacity | TBC |
| Oil cooler included | true |
| Canopy | Optional foldable front-mounted or four-column ROPS canopy |
| Controls | ISO - Pilot Control |
| Certification | CE and Euro Stage V |
| Overall size | 1100 mm W × 2100 mm L × 2193 mm H (including canopy) |
| Driving speed | 2 km/h |
| Swing speed | TBC |
| Bucket digging force | 13.7 kN |
| Maximum noise LWA | 93 dB(A) |
| Track width | TBC |
| Track length | TBC |
| Attachment specification | 25 mm pin; 90 mm dipper gap; pin-centre TBC |
| Warranty | 1 year or 1,200 hours - parts and labour |
| Maximum digging height | 2745 mm |
| Maximum digging depth | 1600 mm |
| Fuel capacity | TBC |
Add this product to your enquiry basket to request a brochure, quotation or both. Online payment is not active at this stage.
